INA RWU25-E-HL-V3-G1 Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 5,447.00 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
23 |
| Dış (D) MM |
48 |
| En (B) MM |
107 |
| İç (d) Inch |
0.9055 |
| Dış (D) Inch |
1.8898 |
| En (B) Inch |
4.2126 |
| Ağırlık |
0.79 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
48 |
| Overall length carriage (L) mm |
107 |
| Dynamic load rating (C) |
33500 |
| Dynamic load rating (C 0) |
82000 |
| Static moment rating about X axis (M 0x) |
440 |
| Static moment rating about Y axis (M 0y) |
1200 |
| Static moment rating about Z axis (M 0z) |
1080 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
High, narrow, long carriage with full complement recirculating roller system for linear recirculating roller bearing and guideway assembly, for oil or grease lubrication |
Suffix description
| E |
Version |
| HL |
High, Long Carriage |
| V3 |
Preload Class 3 |
| G1 |
Precision Class 1 |
