INA RWU35-E-V3-G2 Resim 4
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 5,643.66 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
34 |
| Dış (D) MM |
100 |
| En (B) MM |
122,9 |
| İç (d) Inch |
1.3386 |
| Dış (D) Inch |
3.937 |
| En (B) Inch |
4.8386 |
| Ağırlık |
1.75 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
100 |
| Overall length carriage (L) mm |
122,9 |
| Dynamic load rating (C) |
59000 |
| Dynamic load rating (C 0) |
140000 |
| Static moment rating about X axis (M 0x) |
1200 |
| Static moment rating about Y axis (M 0y) |
2150 |
| Static moment rating about Z axis (M 0z) |
1950 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Standard carriage with full complement recirculating roller system for linear recirculating roller bearing and guideway assembly, for oil or grease lubrication |
Suffix description
| E |
Version |
| V3 |
Preload Class 3 |
| G2 |
Precision Class 2 |
